1.For combination of 3/4KW inverter with 150AH battery to generate electricity

2.High quality solar panels can be used in most life scenarios such as shops, houses, garages, yachts, etc.

3.Excellent quality allows you to work well on cloudy and snowy days and still generate electricity

4.Simple placement, ecological configuration makes it more convenient to use

Open Circuit Voltage(Voc/V):37.26
Short Circuit Current(Isc/A):13.79
Voltage at Maximum Power(Vmp/V):31.3
Current at Maximum Power(Imp/A):13.1
Module Efficiency%:20.97
Operating Temperature:-40°C~+85°C
Maximum System Votage:1000/1500V
Electrical Data(NMOT)
Maximum Power(Pmax/W):308
Open Circuit(Voc/V):34.27
Open Circuit Current(Isc/A):11.27
Voltage at Maximum Power(Vmp/V):28.49
Current at Maximum Power(Imp/A):10.82
Mechanical Data:
Cell Type:182*91mm Mono
Cell Orientation:108(6*18)
Glass:3.2mm high transmittance
Black sheet:Anti-aging film
Frame Material:Anodized aluminum alloy
Junction Box:Protection class IP68
Connector:MC4 compatible connector
(each single panel)Module Dimensions:1724*1134*35mm
Weight:22kg
